Control, Management and Data Interfaces
343
Control, Management and Data Interfaces
Ethernet Management Interface
Item
Specification
Number of connectors
1
Type of connector
Eight-pin RJ-45
Ethernet type
10/100/1000BASE-T
Required setup
IP address, default gateway and subnet mask
Ethernet Data Interface
Item
Specification
Number of connectors
1
Type of connector
Eight-pin RJ-45
Ethernet type
10/100/1000BASE-T
Required setup
IP address, default gateway and subnet mask
RS-232 Data Interface
Item
Specification
Connector type
9-pin sub-D female
Data rates
RS-232 asynchronous data at selectable rates up
to 38.4 kb/s: 300, 1200, 2400, 4800, 9600, 19,200,
38,400 b/s
Alarm Interface
Item
Specification
Number of outputs
3, each having one set of contacts closed and one
set open during normal operation. Alarms are
signaled by reversing the polarity of the two
contact sets.
