Cisco D9858 User Manual

About the Front Panel
35
LED
Signal
State/Color
Explanation
Green
Flashing indicates one of the following
conditions:

difficulty with an input, route, or output.

one or more RF inputs, or the ASI input are
not synchronized.

one or more outputs are routed, but muted
by a fault condition.

no RF signal is present or detected, or it is
muted.

transcoder is not authorized to receive the
program.
Off
Off indicates all of the following conditions:

no RF input signal is available, enabled or
detected, or the input is muted.

no ASI input is present

no valid inputs are available.
Navigation/Selection Keypad
Throughout this manual, there are references to parts of a keypad on the front of the
receiver. The navigation keys (LEFT, RIGHT, UP and DOWN) and the SELECT key
are the primary controllers. Each navigation key performs various functions,
depending on the current state of the menu system (that is, sometimes the left
navigation key backspaces over an entry and sometimes moves the cursor to a
different menu item). Once the cursor is over the desired function, pressing the
SELECT (center key) key selects the current item. Pressing the SELECT key stores
any entered values.
The following is the Navigation/Selection keypad, which changes its function,
depending on the current state of the menu:
The following table shows which parts of this integral interface are being referenced
by which term.
