Setup Menu
To view the Setup menu from the Main menu, press the RIGHT arrow key once and
the SELECT key. The Setup menu is split into eight sections: Administration, TS
Input, IP, Services, Outputs, CA, Alarms/Warnings, and Noise Cutoff. For
instructions on how to select and store settings, see About the Front Panel (on page
34).
The Setup menu allows you to set all the parameters associated with the following:
 Administration - lock level, password, factory reset, keypad lock, download
mode, and date and time
 TS Input - frequency parameters for acquiring and locking on to an RF signal, or
receiving an ASI input
 IP - parameters for setting up the Ethernet ports
 Services - audio video, captions, and VBI
 Outputs - alarm relays, cue tone/cue trigger setup, parameters for setting up the
transport stream out, which includes DPM and transcoding
 CA - conditional access
 Alarms/Warnings - enables alarms/warnings traps and relays
 Noise Cutoff - muting thresholds
 DR - global, backup channel, and backup transport parameters for disaster
recovery
The Setup menu has the following structure:
