Cisco D9858 User Manual

Chapter 4 Front Panel Operation
52
Menu Item
Description
Parameters
SR Event Type
Indicates the type of service
replacement event.
None - Indicates that no service
replacement event is scheduled.
Scheduled - Indicates that all
transcoders will tune to the alternate
program at the scheduled time. This
status applies to PE1 and PE2 for D9858
or PE1 only for D9858-1.
CA - Indicates that only transcoders
unauthorized to view the scheduled
program will tune to the alternate
program according to the selected
authorization tier bits. This status
applies to PE1 and PE2 for D9858 or
PE1 only for D9858-1.
Cue Trigger - Indicates that only
transcoders authorized by the Cue
Trigger mask will tune to the scheduled
program/event.
Note: The Cue Trigger service
replacement event type is not
supported in the current release.
SR Event Start
Displays the start time of the
service replacement event when
one is scheduled; otherwise, the
default start time is displayed. The
default start time is 2007/09/01
00:00:00.
SR Event End
Displays the end time of the service
replacement event when one is
scheduled; otherwise, the default
end time is displayed. The default
end time is 2007/09/01 00:00:00.
Status Menu: TS Output
Output Status
Menu Item
Description
Parameters
Output
Indicates the output type.
ASI or MPEGoIP
Rate (Mbps)
Indicates the current output bit rate.
0 to 213 Mbps
Free (Mbps)
Indicates the available bandwidth, in Mbps
(without stuffing).
