Setting the DPM Mode
17
Setting the DPM Mode
A program can be set to one of three Digital Program Mapping (DPM) modes, either
Drop, Pass, Map, or Xcode. For more information, see TS Out - DPM (on page 99).
LCD Setting
Description
Drop
Removes the service and its associated PMT reference
from the transport output.
Pass
Permits the source content and PMT reference to appear
in the transport output with the same references unless
the source material is mapped on another PE.
Map
Provides the flexibility to define all the outgoing PID
numbers for a PE, including those not currently on
transmission.
Xcode
Provides the flexibility to define all the outgoing PID
numbers for a PE, including those not currently on
transmission, as in Map mode, plus the video PID is
transcoded to output at the rate and settings defined for
the transcode channel.
1 Press MENU to display the Main Menu.
2 Press to move to the Setup menu. Press SELECT.
3 Press four times to move to the Outputs menu. Press SELECT.
4 Press to move to the TS Out menu. Press SELECT.
5 Press twice to move to the DPM menu. Press SELECT.
6 Press SELECT to access the Global menu.
7 Press SELECT to choose ASI for Resync All. Press and then press SELECT to
continue.
8 Press MENU. Press to move to the ASI menu. Press SELECT. Verify the PE1
”InCh” and ”OutCh” programs.
9 Press three times to choose Act. Press SELECT. Use to select the DPM
mode. Xcode (Transcode) is the most common mode. Press SELECT. Press
APPLY. Press SELECT to save the changes.
10 Press three times to choose PE1. Press SELECT. Use to select PE2. Press
SELECT. Verify the PE2 “InCh” and “OutCh” programs.
11 Press three times to choose Act. Press SELECT. Use to select the DPM
mode. Xcode (Transcode) is the most common mode. Press SELECT. Press
APPLY.
12 Press MENU six times to return to the startup screen.
