Chapter 4 Front Panel Operation
36
Button
Function
LEFT Arrow key
When moving through menus,
it highlights the menu item to
the left. When entering data, it
moves the cursor to the left. In
some menus, it backspaces
over the data entry.
RIGHT Arrow
key
When moving through menus,
it highlights the menu item to
the right. When entering data,
it moves the cursor to the
right.
UP Arrow key
Highlights the menu item
above.
DOWN Arrow
key
Highlights the menu item
below.
SELECT key
Runs the highlighted
command or opens the
highlighted menu.
INFO key
Press the key on the lower left
of the numeric keypad for
context-sensitive help
messages, when available.
When entering characters in
numeric or alphanumeric
fields, this key can be used to
toggle between uppercase and
lowercase.
MENU key
Press the key on the lower
right of the numeric keypad.
Starts the on-screen display.
Also functions as the Escape
key so you can back out of
menus and data entry fields.
