Cisco D9858 User Manual

Chapter 4 Front Panel Operation
110
Transcode
Menu Item
Description
Parameters
PE
This selects the transcoder
index as referenced by DPM.
PE1 or PE2
Note: The single channel
transcoder (D9858-1) supports one
Program Entry (PE1) only.
Video Mode
This selects the transcode
channel video mode.
Auto - Leaves the input video
format and resolution unchanged.
For example, SD in - SD out, HD in
- HD out.
SD Output - Down-converts from
HD to SD when receiving an HD
input signal. SD horizontal
resolution will follow the SD Res
parameter set on this menu.
HD Output - Up-converts from SD
to HD1080i when receiving an SD
input signal. HD horizontal
resolution will follow the HD Res
parameter on this menu.
HD720p - Sets the output vertical
resolution to HD720p regardless of
the input resolution.
HD1080i - Sets the output vertical
resolution to HD1080i, regardless
of the input resolution.
HD HRes
This selects the transcode
channel HD horizontal output
video resolution.
Full or 3/4
Setting
Description
Input
Resolution
Output
Resolution
Full
1080i
1920
3/4
1080i
1440
Full
720p
1280
3/4
720p
960
SD HRes
This selects the transcode
channel SD horizontal output
video resolution.
352, 480, 528, 544, 704, or 720
HD/SD B/R Mode
This selects the transcode
channel output bit rate mode.
CBR or VBR
