Cisco D9858 User Manual

Chapter 4 Front Panel Operation
122
Menu Item
Description
Parameters
Trnsprt(DVBS Marg)
Cutoff
Trnsprt(DVBS2 Marg)
Cutoff
Sets the DVB-S and DVB-S2
Carrier to Noise margins, in dB,
below the transport outputs that
will be muted.
The receiver uses these
thresholds to determine when to
mute the transport in the event
of a noisy signal, poor, or loss of
signal condition.
-30.0 to 30.0
This setting must be below the
respective Restore value.
The default is 0.0.
Note: Muting Control must be set
to Enable for these settings to be
active.
Trnsprt(DVBS Marg)
Restore
Trnsprt(DVBS2 Marg)
Restore
Sets the DVB-S and DVB-S2
Carrier to Noise margins, in dB,
above the transport outputs that
will be muted.
The receiver uses these
thresholds to determine when to
restore the transport after it has
been muted.
-30.0 to 30.0
This setting must be above the
respective Cutoff value.
The default is 0.1.
Note: Muting Control must be set
to Enable for these settings to be
active.
The following displays the Transport Default C/N Margin
Relationship
Audio(DVBS Marg)
Cutoff
Audio(DVBS2 Marg)
Cutoff
Sets the DVB-S and DVB-S2
Carrier to Noise margins, in dB,
below the audio outputs that
will be muted.
The receiver uses these
thresholds to determine when to
mute the audio in the event of a
noisy, poor, or loss of signal
condition.
-30.0 to 30.0
This setting must be below the
respective Restore value.
The default is 0.0.
Note: Muting Control must be set
to Enable for these settings to be
active.
