Cisco D9858 User Manual

Chapter 4 Front Panel Operation
130
Menu Item
Description
App Safe
Indicates the version of the factory loaded safe application.
App Safe Limit
Indicates the version of the oldest application that can be
installed on the current unit. If this value is zero, the oldest
application limit is the App Safe version. If this is greater than
zero, the shown value or older and the App Safe version is the
limit. Older applications will not be installed.
Primary
Boot/Secondary
Boot
Indicates the versions of the primary and secondary
processors' boot code.
FPPIC
Indicates the version of the front panel PIC microcontroller.
FPGA Safe
Indicates the version of the factory loaded safe Field
Programmable Gate Array (FPGA) code.
FPGA Current
Indicates the version of the current Field Programmable Gate
Array (FPGA) code.
Ver Register
Indicates the version of FPGA code read from the FPGA.
CPLD Primary,
CPLD Secondary
Indicates the versions of the current primary and secondary
Complex Programmable Logic Device (CPLD).
Application, Select,
Erase
Application - Select between all versions of the application
loaded on the current unit.
Select - Select and then scroll to Yes to reboot the unit and load
the selected application. You will be prompted to continue or
abort this operation.
Note: Selecting an application will cause the unit to reboot
and interrupt service.
Erase - Select to erase the selected application. You will be
prompted continue or abort this operation. You cannot erase
the safe application or the current application. While an
application is being erased, the busy indicator will appear.
You cannot erase another application until it is complete.
Note: You cannot reboot or remove applications during a
download or erase. You must stop the download first. For
more information on aborting the download, see Setup Menu:
Admin (on page 58).
