Cisco D9858 User Manual

Chapter 5 Web GUI Setup and Monitorin g
176
WSS Mode
Description
Passthrough
Passes WSS unmodified as received by the receiver.
Auto:Create
Creates WSS to output the correct aspect ratio when performing
aspect ratio conversion.
Auto:Modify
If WSS is present in the input stream, it is modified to output the
correct aspect ratio when performing aspect ratio conversion. If
WSS is not present in the input, no WSS will be present in the
output.
Suppress
Removes WSS output.
7 Check the Enable Banner Display check box to display alarms and warnings on
the on-screen display (for example, TV monitor).
8 Click Apply.
Viewing the Video Status
The Video Status area displays the current video settings, and the encoding, bit rate,
FPS and aspect ratio of the incoming signal. The fields are read-only. The following
table describes the video status information displayed:
Video Status
Description
Primary Video
Output
Indicates the actual output video format (Auto, HD 720p, HD 1080i,
or SD).
Standard Definition
Output
Displays the actual standard definition format of the primary video
output if the PV Output is set to SD.
Aspect Ratio
Displays the standard definition aspect ratio of your TV monitor.
Wide Screen
Signalling
Displays the Wide Screen Signaling output mode.
Encoding Format
The input stream type of the received signal/program.
Bit Rate (Mbps)
Indicates the bit rate of the input video stream, in Mbps.
Frame Rate (fps)
Indicates the frame rate of the input video stream.
3:2 Pulldown
Indicates whether 3:2 pulldown is detected, was recently detected,
or not detected in the input video stream (Yes, Recent, or No).
