Chapter 5 Web GUI Setup and Monitoring
Leaves the input video format and resolution
unchanged. For example, SD in - SD out, HD
in - HD out.
Down-converts from HD to SD when
receiving an HD input signal. SD horizontal
resolution will follow the HRes parameter
set in the SD Settings area below.
Up-converts from SD to HD1080i when
receiving an SD input signal. HD horizontal
resolution will follow the HRes parameter
set in the HD Settings area below.
4 Click Apply.
Configuring Transcoder Settings
Select the channel on which you want to configure settings and click Transcoder
Config. The Transcoder Settings dialog box is displayed.
If the selected channel is set to HD Output, proceed as follows:
1 In the HD Settings area, select the transcode channel HD horizontal output
video resolution from the HRes drop-down list. You can select Full or 3/4. The
following table displays the settings:
To Next Page
