Chapter 5 Web GUI Setup and Monitorin g
5 The Alarm Setup area displays a list of the alarm/fault messages. For more
information on alarm messages, refer to D9858 Transcoder Alarm Messages (on
page 272).
6 From the Enable/Disable drop-down list, choose Yes and the alarm message will
be reported. Choose No and the alarm is disabled and the Relay and Trap
settings are ignored.
Note: Enable/Disable must be set to Yes for the Relay and Trap settings to be
functional.
7 If current alarm is enabled, set Trap to Yes and the SNMP trap message will be
sent when the alarm is set or cleared.
Note: No is a read only value that indicates the setting is Yes, but is currently
being suppressed because the alarm is disabled (Enb is set to No).
8 If current alarm is enabled, choose Yes from the Relay drop-down list for the
rear panel alarm relay to be triggered when the alarm is set or cleared.
Note: No is a read only value that indicates the setting is Yes, but is currently
being suppressed because the alarm is disabled (Enb is set to No).
9 Click Apply.
To Set Up Warnings
Proceed as follows to set up the warning parameters:
1 From the Alarm Setup page, click the Warning Setup link at the bottom left hand
corner of the page. The Warning Setup page is displayed.
2 Check the Enable Alarm/Warning Front Panel Reminder check box and the
warning flashes on the LCD display for a two-second interval every 10 seconds.
The warning will continue to flash periodically until it is either cleared or the
Enable Alarm/Warning Front Panel Reminder is de-selected.
