Cisco D9858 User Manual

Video Inputs/Outputs and Processing
337
Item
Specification
Bit Rate
10 to 25 Mb/s
Analog SD Video Output
Item
Test Signal
Specification CVBS1
Specification CVBS2
Number of
Channels
One SD source
program
One SD source program
Video
Decompression
MPEG-2 4:2:0
MPEG-2 4:2:0
Output
Impedance
75 Ω
75 Ω
525 Line
Bar level
NTC-7 comp
700 mV ± 7 mV (± 1%)
700 mV ± 35 mV (± 5%)
Line Time
Distortion
VITS17
≤ 1%
≤ 1%
Bar Tilt
NTC-7 comp
< 0.5%
< 0.5%
Sync Level
NTC-7 comp
40 IRE ± 0.5 IRE
40 IRE ± 2.0 IRE
DC Offset
NTC-7 comp
± 100 mV
± 100 mV
Chrominance-
to-Luminance
Gain Inequality
NTC-7 comp
100 ± 5%
100 ± 5%
Chrominance-
to-Luminance
Phase Inequality
NTC-7 comp
< 20 ns
< 20 ns
K factor K 2T
NTC-7 comp
< 1%
< 1%
Jitter
< 5 ns
< 5 ns
Frequency
Response
FCC multi-burst
0.5 MHz, 0 dB
1.25 MHz, 0 dB ± 0.2 dB
2 MHz, 0 dB ± 0.2 dB
3 MHz, 0 dB ± 0.3 dB
3.58 MHz, 0 dB ± 0.3 dB
4.1 MHz, 0 dB ± 0.3 dB
0.5 MHz, 0 dB
1.25 MHz, 0 dB ± 0.2 dB
2 MHz, 0 dB ± 0.2 dB
3 MHz, 0 dB ± 0.3 dB
3.58 MHz, 0 dB ± 0.3 dB
4.1 MHz, 0 dB ± 0.3 dB
Differential Gain
NTC-7 comp
< 3.0%
< 3.0%
