Cisco D9858 User Manual

Status Menu
49
Menu Item
Description
Parameters
Pilot Present
Indicates whether a Pilot is present for
the received signal. The Pilot is set on
the modulator for input signal
synchronization purposes.
Yes, No, or N/A
C/N (dB)
Indicates the current Carrier-to-Noise
ratio.
in dB
C/N Margin (dB)
Indicates the current Carrier-to-Noise
Margin for the received signal. The
Carrier-to-Noise margin is the actual
distance that C/N is from the noise
threshold.
Values can be displayed in the
range of -32.0 to +30.0 dB.
PER
Indicates the current PER (Packet Error
Rate) of the received signal (DVB-S2).
PVBER
Indicates the PV (Post-Viterbi) BER for
the received signal (DVB-S).
LDPCBER
Indicates the LDPC (Low Density Parity
Check) error rate for the received signal
(DVB-S2).
AFC (MHz)
Indicates the current Automatic
Frequency Control count.
in MHz
UEC
Indicates the current Uncorrected Error
Count for the received signal.
CEC
Indicates the current Corrected Error
Count for the received signal (DVB-S).
Clear Counts
Select this option to clear the error
counters.
ASI Link
Indicates whether there is a transport
stream link error.
Error, Ok, or N/A
Transport
Indicates the current transport
synchronization status.
Error, Ok, or N/A
Packet Size
Indicates the packet size (in bytes) for
the ASI input.
188, 204, or N/A
Net Name
Indicates the name assigned to the
network.
Up to 12 alphanumeric characters.
