Cisco D9858 User Manual

Chapter 4 Front Panel Operation
66
Menu Item
Description
Parameters
OrbPos
This is the location in orbit of the satellite
currently being used. The satellite position (in
degrees) in combination with the direction
(either E (East) or W (West)) denotes the
satellite position the dish connected to the
current RF Input should point to. This is used
when the satellite is not available in the look-
up menu list.
For manual configuration, enter the location of
the satellite using the numerical keypad. The
receiver will not recognize the satellite name
and identify it as Unknown.
Degrees.
E/W
Denotes the satellite position the dish
connected to the current RF Input should point
to. This is used when the satellite is not
available in the look-up menu list.
E, W or NA.
Pol
Marks the polarity of the signal connected to
this RF input.
H (horizontal), Vert
(vertical), A (Auto). Auto
is only applicable when
LNB Power is set to H-NIT
or V-NIT.
Validate Orbital
Position
This option allows you to configure and
validate the RF inputs to match those expected
by the network. The transcoder will check to
see if all the frequencies in the Network
Information Table (NIT) can be tuned to.
–
Orbital Position
Validation Date
This displays the last date that the ‘Validate
Orbital Position’ operation was performed.
N/A.
Freq (GHz)
This is the current Downlink operating
frequency used by the receiver for tuning the
received digital signal.
0.0 to 15.0 GHz.
SymRate
This is the symbol rate. The symbol rate must
match that of the transmitted signal.
1.0 to 45.0 Ms/s for DVB-
S.
1.0 to 30.0 Ms/s for DVB-
S2 if Pilot Present is set to
Yes.
5.0 to 30.0 Ms/s for DVB-
S2 if Pilot Present is set to
No.
FEC
Select the Forward Error Correction (FEC)
inner code rate. The FEC must match the FEC
of the transmitted signal.
1/2, 2/3, 3/4, 5/6, 7/8, or
Auto.
