1040
Configuring EtherChannels
How to Configure EtherChannels
Configuring the LACP Hot-Standby Ports
This task is optional.
3. pagp learn-method physical-port Selects the PAgP learning method.
By default, aggregation-port learning is selected, which means
the switch sends packets to the source by using any of the ports
in the EtherChannel. With aggregate-port learning, it is not
important on which physical port the packet arrives.
Select physical-port to connect with another switch that is a
physical learner. Make sure to configure the port-channel
load-balance global configuration command to src-mac as
described in the Configuring EtherChannel Load Balancing,
page 1038.
The learning method must be configured the same at both ends
of the link.
4. pagp port-priority priority Assigns a priority so that the selected port is chosen for packet
transmission.
For priority, the range is 0 to 255. The default is 128. The higher
the priority, the more likely that the port will be used for PAgP
transmission.
5. end Returns to privileged EXEC mode.
Command Purpose
Command Purpose
1. configure terminal Enters global configuration mode.
2. lacp system-priority priority Configures the LACP system priority.
For priority, the range is 1 to 65535. The default is 32768.
The lower the value, the higher the system priority.
3. interface interface-id Specifies the port to be configured, and enters interface
configuration mode.
4. lacp port-priority priority Configures the LACP port priority.
For priority, the range is 1 to 65535. The default is 32768. The
lower the value, the more likely that the port will be used for
LACP transmission.
5. end Returns to privileged EXEC mode.
