561
Configuring Network Security with ACLs
How to Configure Network Security with ACLs
Creating Named MAC Extended ACLs
Applying a MAC ACL to a Layer 2 Interface
Command Purpose
1. configure terminal Enters global configuration mode.
2. mac access-list extended name Defines an extended MAC access list using a name.
3. {deny | permit} {any | host source MAC
address | source MAC address mask} {any |
host destination MAC address | destination
MAC address mask} [type mask | lsap lsap
mask | aarp | amber | dec-spanning |
decnet-iv | diagnostic | dsm | etype-6000 |
etype-8042 | lat | lavc-sca | mop-console |
mop-dump | msdos | mumps | netbios |
vines-echo |vines-ip | xns-idp | 0-65535]
[cos cos]
In extended MAC access-list configuration mode, specifies to
permit or deny any source MAC address, a source MAC address
with a mask, or a specific host source MAC address and any
destination MAC address, destination MAC address with a mask,
or a specific destination MAC address.
(Optional) You can also enter these options:
type
mask—Specifies an arbitrary EtherType number of a
packet with Ethernet II or SNAP encapsulation in decimal,
hexadecimal, or octal with optional mask of don’t care bits
applied to the EtherType before testing for a match.
lsap lsap mask—Specifies an LSAP number of a packet with
IEEE 802.2 encapsulation in decimal, hexadecimal, or octal
with optional mask of don’t care bits.
aarp | amber | dec-spanning | decnet-iv | diagnostic | dsm
| etype-6000 | etype-8042 | lat | lavc-sca | mop-console |
mop-dump | msdos | mumps | netbios | vines-echo
|vines-ip | xns-idp—Specifies a non-IP protocol.
cos cos—Specifies an IEEE 802.1Q cost of service number
from 0 to 7 used to set priority.
4. end Returns to privileged EXEC mode.
Command Purpose
1. configure terminal Enters global configuration mode.
2. interface interface-id Identifies a specific interface, and enters interface configuration
mode. The interface must be a physical Layer 2 interface (port
ACL).
3. mac access-group {name} {in} Controls access to the specified interface by using the MAC
access list.
Port ACLs are supported only in the inbound direction.
4. end Returns to privileged EXEC mode.
