Cisco IE 4000 Software Configuration Guide

269
Configuring SGT Exchange Protocol over TCP (SXP) and Layer 3 Transport
Configuring Cisco TrustSec Caching
This example shows how to configure Cisco TrustSec caching, including non-volatile storage:
Router# configure terminal
Router(config)# cts cache enable
Router(config)# cts cache nv-storage bootdisk:
Router(config)# exit
Clearing the Cisco TrustSec Cache
To clear the cache for Cisco TrustSec connections, perform this task:
This example shows how to clear the Cisco TrustSec cache:
Router# clear cts cache
Command Purpose
1.
Router# configure terminal
Enters configuration mode.
2.
Router(config)# [no] cts cache enable
Enables caching of authentication, authorization and
environment-data information to DRAM. The default is
disabled.
The no form of this command deletes all cached
information from DRAM and non-volatile storage.
3.
Router(config)# [no] cts cache
nv-storage {bootdisk: | bootflash: |
disk0:} [directory dir-name]
When DRAM caching is enabled, enables DRAM
cache updates to be written to non-volatile storage.
Also enables DRAM cache to be initially populated
from non-volatile storage when the device boots.
4.
Router(config)# exit
Exits configuration mode.
Command Purpose
1.
Router# clear cts cache
[authorization-policies [peer] |
environment-data | filename filename |
interface-controller [type slot/port]]
Clears the cache for Cisco TrustSec connection
information.
