Cisco IE 4000 Software Configuration Guide

479
Configuring SPAN and RSPAN
How to Configure SPAN and RSPAN
Creating an RSPAN Source Session
Command Purpose
1. configure terminal Enters global configuration mode.
2. no monitor session {session_number | all |
local | remote}
Removes any existing RSPAN configuration for the session.
session_number—The range is 1 to 68.
all—Removes all RSPAN sessions
local—Removes all local sessions
remote—Removes all remote SPAN sessions.
3. monitor session session_number source
{interface interface-id | vlan vlan-id} [, | -]
[both | rx | tx]
Specifies the RSPAN session and the source port (monitored port).
session_number—The range is 1 to 68.
Enter a source port or source VLAN for the RSPAN session:
 interface-id—Specifies the source port to monitor. Valid
interfaces include physical interfaces and port-channel logical
interfaces (port-channel port-channel-number). Valid
port-channel numbers are 1 to 10.
 vlan-id—Specifies the source VLAN to monitor. The range is 1 to
4096 (excluding the RSPAN VLAN).
A single session can include multiple sources (ports or VLANs),
defined in a series of commands, but you cannot combine
source ports and source VLANs in one session.
(Optional) [, | -]—Specifies a series or range of interfaces. Enter a
space before and after the comma; enter a space before and after
the hyphen.
(Optional) Specify the direction of traffic to monitor. If you do not
specify a traffic direction, the source interface sends both sent and
received traffic.
 both—Monitors both received and sent traffic.
 rx—Monitors received traffic.
 tx—Monitors sent traffic.
4. monitor session session_number
destination remote vlan vlan-id
Specifies the RSPAN session and the destination RSPAN VLAN.
session_number—Enters the number defined in Step 3.
vlan-id—Specifies the source RSPAN VLAN to monitor.
5. end Returns to privileged EXEC mode.
6. show monitor [session session_number]
show running-config
Verifies the configuration.
7. copy running-config startup-config (Optional) Saves the configuration in the configuration file.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
