Configuring Embedded Event Manager
Information About Embedded Event Manager
Figure 96 Embedded Event Manager Core Event Detectors
See EEM Configuration for Cisco Integrated Services Router Platforms Guide for examples of EEM deployment.
This section includes the following topics:
 Event Detectors, page 790
 Embedded Event Manager Actions, page 791
 Embedded Event Manager Policies, page 792
 Embedded Event Manager Environment Variables, page 792
 EEM 3.2, page 792
Event Detectors
EEM software programs known as event detectors determine when an EEM event occurs. Event detectors are separate
systems that provide an interface between the agent being monitored, for example SNMP, and the EEM polices where
an action can be implemented.
EEM allows these event detectors:
 Application-specific event detector—Allows any EEM policy to publish an event.
 IOS CLI event detector—Generates policies based on the commands entered through the CLI.
 Generic Online Diagnostics (GOLD) event detector—Publishes an event when a GOLD failure event is detected on a
specified card and subcard.
 Counter event detector—Publishes an event when a named counter crosses a specified threshold.
