Cisco IE 4000 Software Configuration Guide

32
Configuring Interfaces
Configuring Ethernet Interfaces
Default Ethernet Interface Configuration
Table 6 on page 32 shows the Ethernet interface default configuration for NNIs, and Table 7 on page 33 shows the
Ethernet interface default configuration for UNIs and ENIs. For more details on the VLAN parameters listed in the table,
see Configuring VLANs, page 271
Note: To configure Layer 2 parameters, if the interface is in Layer 3 mode, you must enter the switchport interface
configuration command without any parameters to put the interface into Layer 2 mode. This shuts down the interface
and then re-enables it, which might generate messages on the device to which the interface is connected. When you
put an interface that is in Layer 3 mode into Layer 2 mode, the previous configuration information related to the affected
interface might be lost, and the interface is returned to its default configuration.
Table 6 Default Ethernet Configuration for NNIs
Feature Default Setting
Operating mode Layer 2 or switching mode (switchport command).
Allowed VLAN range VLANs 1– 4094.
Default VLAN (for access ports) VLAN 1 (Layer 2 interfaces only).
Native VLAN (for 802.1Q trunks) VLAN 1 (Layer 2 interfaces only).
VLAN trunking Switchport mode access (Layer 2 interfaces only).
Port enable state Enabled.
Port description None defined.
Speed Autonegotiate.
Duplex mode Full.
802.3x flow control Flow control is set to receive: off. It is always off for sent packets.
EtherChannel Disabled on all Ethernet ports. See Configuring EtherChannels,
page 1027
Port blocking (unknown multicast and unknown
unicast traffic)
Disabled (not blocked) (only Layer 2 interfaces).
Broadcast, multicast, and unicast storm control Disabled.
Port security Disabled (only Layer 2 interfaces).
Port Fast Disabled.
Auto-MDIX Enabled.
Note: The switch might not support a pre-standard powered
device—such as Cisco IP phones and access points that do not fully
support 802.3af/802.3at—if that powered device is connected to the
switch through a crossover cable. This is regardless of whether
auto-MIDX is enabled on the switch port.
Power over Ethernet (PoE) Enabled (auto).
Cisco Discovery Protocol (CDP) Enabled.
VMPS Not configured.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
