Cisco IE 4000 Software Configuration Guide

285
Configuring VLANs
How to Configure VLANs
Deleting a VLAN
Assigning Static-Access Ports to a VLAN
Creating an Extended-Range VLAN
Command Purpose
1. configure terminal Enters global configuration mode.
2. no vlan vlan-id Removes the VLAN by entering the VLAN ID.
3. end Returns to privileged EXEC mode.
Command Purpose
1. configure terminal Enters global configuration mode
2. interface interface-id Enters the interface to be added to the VLAN.
3. switchport mode access Defines the VLAN membership mode for the port (Layer 2 access
port).
4. switchport access vlan vlan-id Assigns the port to a VLAN. Valid VLAN IDs are 1 to 4096.
5. end Returns to privileged EXEC mode.
Command Purpose
1. configure terminal Enters global configuration mode.
2. vtp mode transparent Configures the switch for VTP transparent mode and disables VTP.
Note: This step is not required for VTP version 3.
3. vlan vlan-id Enters an extended-range VLAN ID and enters VLAN configuration mode.
The range is 1006 to 4096.
4. mtu mtu-size (Optional) Modifies the VLAN by changing the MTU size.
Note: Although all VLAN commands appear in the CLI help, only the mtu
mtu-size, private-vlan, and remote-span commands are supported for
extended-range VLANs.
5. remote-span (Optional) Configures the VLAN as the RSPAN VLAN. See Configuring a
VLAN as an RSPAN VLAN, page 478.
6. end Returns to privileged EXEC mode.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
