Cisco IE 4000 Software Configuration Guide

226
Configuring IEEE 802.1x Port-Based Authentication
How to Configure IEEE 802.1x Port-Based Authentication
Configuring a Guest VLAN
When you configure a guest VLAN, clients that are not 802.1x-capable are put into the guest VLAN when the server does
not receive a response to its EAP request/identity frame. Clients that are 802.1x-capable but that fail authentication are
not granted network access. The switch supports guest VLANs in single-host or multiple-hosts mode.
Configuring a Restricted VLAN
When you configure a restricted VLAN on a switch, clients that are 802.1x-compliant are moved into the restricted VLAN
when the authentication server does not receive a valid username and password. The switch supports restricted VLANs
only in single-host mode.
Command Purpose
1. configure terminal Enters global configuration mode.
2. interface interface-id Specifies the port to be configured, and enters interface configuration
mode.
3. switchport mode access
or
switchport mode private-vlan host
Sets the port to access mode
or
Configures the Layer 2 port as a private-VLAN host port.
4. authentication port-control auto Enables 802.1x authentication on the port.
5. authentication event no-response
action authorize vlan vlan-id
Specifies an active VLAN as an 802.1x guest VLAN. The range is
1 to 4096.
You can configure any active VLAN except an internal VLAN (routed port),
an RSPAN VLAN, a primary private VLAN, or a voice VLAN as an 802.1x
guest VLAN.
6. end Returns to privileged EXEC mode.
7. show authentication interface
interface-id
Verifies your entries.
8. copy running-config startup-config (Optional) Saves your entries in the configuration file.
Command Purpose
1. configure terminal Enters global configuration mode.
2. interface interface-id Specifies the port to be configured, and enters interface configuration
mode.
3. switchport mode access
or
switchport mode private-vlan host
Sets the port to access mode,
or
Configures the Layer 2 port as a private-VLAN host port.
4. authentication port-control auto Enables 802.1x authentication on the port.
5. authentication event fail action authorize
vlan-id
Specifies an active VLAN as an 802.1x restricted VLAN. The range is
1 to 4096.
You can configure any active VLAN except an internal VLAN (routed port),
an RSPAN VLAN, a primary private VLAN, or a voice VLAN as an 802.1x
restricted VLAN.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
