Cisco IE 4000 Software Configuration Guide

194
Configuring IEEE 802.1x Port-Based Authentication
Information About Configuring IEEE 802.1x Port-Based Authentication
Authentication Manager
Port-Based Authentication Methods
Table 29 on page 194 lists the authentication methods supported in these host modes:
 Single host—Only one data or voice host (client) can be authenticated on a port.
 Multiple host—Multiple data hosts can be authenticated on the same port. (If a port becomes unauthorized in
multiple-host mode, the switch denies network access to all of the attached clients.)
 Multidomain authentication (MDA)—Both a data device and voice device can be authenticated on the same switch
port. The port is divided into a data domain and a voice domain.
 Multiple authentication—Multiple hosts can authenticate on the data VLAN. This mode also allows one client on the
VLAN if a voice VLAN is configured.
Table 29 802.1x Features
Authentication Method Mode
Single Host Multiple Host MDA
1
Multiple
Authentication
2
802.1x VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
MAC authentication bypass VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-ID attribute
Downloadable ACL
Redirect URL
VLAN assignment
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
Per-user ACL
Filter-Id attribute
Downloadable ACL
Redirect URL
Standalone web authentication Proxy ACL, Filter-Id attribute, downloadable ACL
2
NAC Layer 2 IP validation Filter-Id attribute
Downloadable ACL
Redirect URL
Filter-Id attribute
Downloadable ACL
Redirect URL
Filter-Id attribute
Downloadable ACL
Redirect URL
Filter-Id attribute
3
Downloadable ACL
Redirect URL
Web authentication as fallback
method
3
Proxy ACL
Filter-Id attribute
Downloadable ACL
Proxy ACL
Filter-Id attribute
Downloadable ACL
Proxy ACL
Filter-Id attribute
Downloadable ACL
Proxy ACL
3
Filter-Id attribute
Downloadable ACL
1. MDA = Multidomain authentication.
2. Also referred to as multiauth.
3. For clients that do not support 802.1x authentication.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
