Cisco IE 4000 Software Configuration Guide

118
Performing Switch Administration
How to Perform Switch Administration
Command Purpose
1. configure terminal Enters global configuration mode.
2. snmp-server host host-addr {traps | informs} {version {1 |
2c | 3}} community-string notification-type
Specifies the recipient of the trap message.
 host-addr—Specifies the name or address of the
NMS.
 traps (the default)—Sends SNMP traps to the
host.
 informs—Sends SNMP informs to the host.
 version—Specifies the SNMP version to
support. Version 1, the default, is not available
with informs.
 community-string—Specifies the string to send
with the notification operation. You can set this
string by using the snmp-server host
command, but we recommend that you define
this string by using the snmp-server
community command before using the
snmp-server host command.
 notification-type—Uses the mac-notification
keyword.
3. snmp-server enable traps mac-notification threshold Enables the switch to send MAC threshold
notification traps to the NMS.
4. mac address-table notification threshold Enables the MAC address threshold notification
feature.
5. mac address-table notification threshold [limit
percentage] | [interval time]
Enters the threshold value for the MAC address
threshold usage monitoring.
 (Optional) limit percentage—Specifies the
percentage of the MAC address table use; valid
values are from 1 to 100 percent. The default is
50 percent.
 (Optional) interval time—Specifies the time
between notifications; valid values are greater
than or equal to 120 seconds. The default is 120
seconds.
6. end Returns to privileged EXEC mode.

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
