Cisco IE 4000 Software Configuration Guide

457
Configuring Port-Based Traffic Control
How to Configure Port-Based Traffic Control
6. switchport port-security
[maximum value [vlan {vlan-list |
{access | voice}}]]
(Optional) maximum—Specifies the maximum number of secure MAC
addresses on the port. By default only 1 MAC address is allowed.
The maximum number of secure MAC addresses that you can configure on a
switch is set by the maximum number of available MAC addresses allowed in
the system. This number is set by the active Switch Database Management
(SDM) template. This number is the total of available MAC addresses,
including those used for other Layer 2 functions and any other secure MAC
addresses configured on interfaces.
(Optional) vlan—Sets a per-VLAN maximum value.
Enter one of these options after you enter the vlan keyword:
 vlan-list—On a trunk port, sets a per-VLAN maximum value on a range of
VLANs separated by a hyphen or a series of VLANs separated by
commas. For nonspecified VLANs, the per-VLAN maximum value is
used.
 access—On an access port, specifies the VLAN as an access VLAN.
 voice—On an access port, specifies the VLAN as a voice VLAN.
Note: The voice keyword is available only if a voice VLAN is configured on a
port and if that port is not the access VLAN. If an interface is configured for
voice VLAN, configure a maximum of two secure MAC addresses.
Command Purpose

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
