Cisco IE 4000 Software Configuration Guide

475
Configuring SPAN and RSPAN
How to Configure SPAN and RSPAN
3. monitor session session_number source
{interface interface-id | vlan vlan-id} [, | -]
[both | rx | tx]
Specifies the SPAN session and the source port (monitored port).
session_number—The range is 1 to 68.
interface-id—Specifies the source port or source VLAN to monitor.
 source interface-id—Specifies the source port to monitor. Valid
interfaces include physical interfaces and port-channel logical
interfaces (port-channel port-channel-number). Valid
port-channel numbers are 1 to 10.
 vlan-id—Specifies the source VLAN to monitor. The range is 1 to
4096 (excluding the RSPAN VLAN).
Note: A single session can include multiple sources (ports or
VLANs), defined in a series of commands, but you cannot combine
source ports and source VLANs in one session.
(Optional) [, | -] Specify a series or range of interfaces. Enter a space
before and after the comma; enter a space before and after the
hyphen.
(Optional) Specify the direction of traffic to monitor. If you do not
specify a traffic direction, the SPAN monitors both sent and received
traffic.
 both—Monitors both received and sent traffic. This is the default.
 rx—Monitors received traffic.
 tx—Monitors sent traffic.
Note: You can use the monitor session session_number source
command multiple times to configure multiple source ports.
Command Purpose

Cisco IE 4000 Specifications

General

Product Type	Switch
Form Factor	DIN Rail Mountable
MAC Address Table Size	8000
Jumbo Frame Support	9216 bytes
Operating Temperature	-40°C to 70°C
Mean Time Between Failures (MTBF)	Over 500, 000 hours
Memory	256 MB DRAM
Mounting	DIN Rail, Wall
Certifications	EN 50121-4
Ports	8 x 10/100Base-TX Ethernet Ports
