D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 105
Cisco TelePresence MX700 and MX800
API Reference Guide
xCommand Cameras SpeakerTrack Whiteboard ActivatePosition
Moves the specified camera in a SpeakerTrack 60 to the position stored with xCommand
Cameras SpeakerTrack Whiteboard StorePosition.
Requires user role: USER
USAGE:
xCommand Cameras SpeakerTrack Whiteboard ActivatePosition Camera: Camera
[WhiteboardId: WhiteboardId]
where
Camera: Left/Right
Select either right or left camera.
WhiteboardId: Integer (1..8)
The id set for the camera position used for the snap-to-whiteboard feature. Currently
only id 1 can be used.
xCommand Cameras SpeakerTrack Whiteboard AlignPosition
Align the position of the other camera on a SpeakerTrack 60 to the first cameras stored
position. You must also set the distance to a whiteboard.
Requires user role: USER
USAGE:
xCommand Cameras SpeakerTrack Whiteboard AlignPosition Cam era: Camera Dista nce:
Distance
where
Camera: Left/Right
Select either right or left camera.
Distance: Integer (300..1500)
Set distance to whiteboard in millimeters. Use an accurate measurement for the feature
to work seamlessly.
xCommand Cameras SpeakerTrack Whiteboard SetDistance
Set the cameras distance to the whiteboard. This information is needed by the SpeakerTrack 60
to frame the whiteboard automatically.
Requires user role: USER
USAGE:
xCommand Cameras SpeakerTrack Whiteboard SetDistance Distance: Distance
[WhiteboardId: WhiteboardId]
where
Distance: Integer (0..65534)
Set distance to whiteboard in centimeters. Use a distance between 0-2000 cm. Use an
accurate measurement for the feature to work seamlessly.
WhiteboardId: Integer (1..8)
The id set for the camera position used for the snap-to-whiteboard feature. Currently
only id 1 can be used.
xCommand Cameras SpeakerTrack Whiteboard StorePosition
Store the position of one of the cameras on a SpeakerTrack 60 as the Snap to Whiteboard
position. Frame the image so that there is room around the whiteboard for the speaker. To use
the Snap to Whiteboard feature it must be enabled with xConfiguration Cameras SpeakerTrack
Whiteboard Mode and tracking must be enabled with xConfiguration Cameras SpeakerTrack
Mode.
Note: You must store a snap-to-whiteboard position for both cameras.
Requires user role: USER
USAGE:
xCommand Cameras SpeakerTrack Whiteboard StorePosition Ca mera: Camera
[WhiteboardId: WhiteboardId]
where
Camera: Left/Right
Select the camera which position you wish to store.
WhiteboardId: Integer (1..8)
You can give the position an id number. Currently the only id that can be used is 1.
