Page #84 background imageLoading...
Page #84 background image
D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 84
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Video Input Connector [1..5] Visibility
Define the visibility of the video input connector in the menus on the user interface.
Requires user role: ADMIN
Default value: Connector 1, 2, 3: IfSignal Connector 4: Always Connector 5: Never
USAGE:
xConfiguration Video Input Connector n Visibility: Visibility
where
Visibility
: Never/Always/IfSignal
Never: When the input source is not expected to be used as a presentation source, set
to Never.
Always: When set to Always, the menu selection for the video input connector will
always be visible on the graphical user interface.
IfSignal: When set to IfSignal, the menu selection for the video input connector will only
be visible when something is connected to the video input.
xConfiguration Video Monitors
A role is assigned to each monitor using the Video Output Connector [n] MonitorRole setting.
The monitor role decides which layout (call participants and presentation) will appear on the
monitor that is connected to this output. Monitors with the same monitor role will get the same
layout; monitors with different monitor roles will have different layouts.
The monitor layout mode that is set in the Video Monitors setting should reflect the number of
different layouts you want in your room setup. Note that some monitors can be reserved for
presentations.
Requires user role: ADMIN
Default value: Auto
USAGE:
xConfiguration Video Monitors: Monitors
where
Monitors
: Auto/Single/Dual/DualPresentationOnly/TriplePresentationOnly/Triple
Auto: The number of monitors connected to the codec is automatically detected, and
the layout is distributed on the monitors according to the MonitorRole settings.
Single: The same layout is shown on all monitors.
Dual: The layout is distributed on monitors with monitor role First and Second. If a
presentation is part of the layout, all participants in the call are shown on monitors with
monitor role First, and the presentation is shown on monitors with monitor role Second.
DualPresentationOnly: All participants in the call are shown on monitors with monitor
role First. If a presentation is part of the layout, the presentation is shown on monitors
with monitor role Second.
Triple: The layout is distributed on monitors with monitor role First, Second and Third.
If a presentation is part of the layout, all participants in the call are shown on monitors
with monitor role First and Second, and the presentation is shown on the monitor with
monitor role Third.
TriplePresentationOnly: All participants in the call are distributed on monitors with
monitor role First and Second. If a presentation is part of the layout, the presentation is
shown on the monitor with monitor role Third.
