xConfiguration SIP ListenPort
Turn on or off the listening for incoming connections on the SIP TCP/UDP ports. If turned off,
the endpoint will only be reachable through the SIP registrar (CUCM or VCS). It is recom-
mended to leave this setting at its default value.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration SIP ListenPort: ListenPort
where
ListenPort : Off/On
Off: Listening for incoming connections on the SIP TCP/UDP ports is turned off.
On: Listening for incoming connections on the SIP TCP/UDP ports is turned on.
xConfiguration SIP Proxy [1..4] Address
The Proxy Address is the manually configured address for the outbound proxy. It is possible to
use a fully qualified domain name, or an IP address. The default port is 5060 for TCP and UDP
but another one can be provided.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Proxy n Ad d ress: "Address"
where
n : Index that identifies the proxy (maximum 4 proxys can be defined). Range: 1..4
Address : String (0, 255)
A valid IPv4 address, IPv6 address or DNS name.
xConfiguration SIP Turn Server
Define the address of the TURN (Traversal Using Relay NAT) server. It is used as a media relay
fallback and it is also used to discover the endpoint's own public IP address.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Turn Server: "Server"
where
Server : String (0, 255)
The preferred format is DNS SRV record (e.g. _turn._udp.<domain>), or it can be a valid
IPv4 or IPv6 address.
xConfiguration SIP Turn UserName
Define the user name needed for accessing the TURN server.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Turn UserName: "UserName"
where
UserName : String (0, 128)
A valid user name.
xConfiguration SIP Turn Password
Define the password needed for accessing the TURN server.
Requires user role: ADMIN
Default value: ""
USAGE:
xConfiguration SIP Turn Password: "Password"
where
Password : String (0, 128)
A valid password.
