D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 63
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Network [1] VLAN Voice Mode
Define the VLAN voice mode. The VLAN Voice Mode will be set to Auto automatically if you
have Cisco UCM (Cisco Unified Communications Manager) as provisioning infrastructure. Note
that Auto mode will NOT work if the NetworkServices CDP Mode setting is Off.
Requires user role: ADMIN
Default value: Auto
USAGE:
xConfiguration Network n VLAN Voice Mod e: Mode
where
n : Index that identifies the network. Range: 1..1
Mode : Auto/Manual/Off
Auto: The Cisco Discovery Protocol (CDP), if available, assigns an id to the voice VLAN.
If CDP is not available, VLAN is not enabled.
Manual: The VLAN ID is set manually using the Network VLAN Voice VlanId setting. If
CDP is available, the manually set value will be overruled by the value assigned by CDP.
Off: VLAN is not enabled.
xConfiguration Network [1] VLAN Voice VlanId
Define the VLAN voice ID. This setting will only take effect if Network VLAN Voice Mode is set
to Manual.
Requires user role: ADMIN
Default value: 1
USAGE:
xConfiguration Network n VLAN Voice VlanId: VlanId
where
n : Index that identifies the network. Range: 1..1
VlanId : Integer (1..4094)
Set the VLAN voice ID.
NetworkServices configuration
xConfiguration NetworkServices CDP Mode
Enable or disable the CDP (Cisco Discovery Protocol) daemon. Enabling CDP will make the
endpoint report certain statistics and device identifiers to a CDP-enabled switch. If CDP is
disabled, the Network VLAN Voice Mode: Auto setting will not work.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration NetworkServices CDP Mode: Mode
where
Mode : Off/On
Off: The CDP daemon is disabled.
On: The CDP daemon is enabled.
xConfiguration NetworkServices H323 Mode
Define whether the system should be able to place and receive H.323 calls or not.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration NetworkServices H323 Mo de: Mode
where
Mode : Off/On
Off: Disable the possibility to place and receive H.323 calls.
On: Enable the possibility to place and receive H.323 calls (default).
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco TelePresence MX200 G2 Specifications

General

Resolution	1920 x 1080
Network	10/100/1000 Ethernet
Product Type	Video conferencing system
Display Size	42 in
Camera	PrecisionHD 1080p Camera
Codec	Cisco TelePresence Codec
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI
Control	Cisco Touch 10
Video Standards	H.264
Connectivity	HDMI
Codec Support	H.264
Resolution (fps)	1080p30
