D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 42
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Audio Output Line [1..6] Channel
Define whether the Audio Line output is a mono signal or part of a multichannel signal.
Requires user role: ADMIN
Default value: Left
USAGE:
xConfiguration Audio Output Line n Chan nel: Channel
where
Channel
: Left/Mono/Right
Left: The Audio Line output signal is the left channel of a stereo signal.
Mono: The Audio Line output signal is a mono signal.
Right: The Audio Line output signal is the right channel of a stereo signal.
xConfiguration Audio Output Line [1..6] Equalizer ID
Select the equalizer ID for the audio source that is connected to the output line.
Requires user role: ADMIN
Default value: 1
USAGE:
xConfiguration Audio Output Line n Equalizer ID: ID
where
n
: Unique ID that identifies the audio line output. Range: 1..6
ID
: Integer (1..8)
Set the equalizer ID.
xConfiguration Audio Output Line [1..6] Equalizer Mode
Define the equalizer mode for the audio source that is connected to the output line.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Audio Output Line n Equalizer Mode: Mode
where
Mode
: Off/On
Off: No equalizer.
On: Enable the equalizer for the audio output line.
xConfiguration Audio Output Line [1..6] Level
Define the audio level on the line output connector.
See the Audio Level table in the Physical Interface Guide for Cisco TelePresence SX80 for a
complete overview of the menu values represented in dB.
Requires user role: ADMIN
Default value: -10
USAGE:
xConfiguration Audio Output Line n Level: Level
where
Level
: Integer (-24..0)
Select a value between -24 and 0, in steps of 1 dB.
