Video configuration
xConfiguration Video DefaultMainSource
Define which video input source shall be used as the main video source.
Requires user role: USER
Default value: 1
USAGE:
xConfiguration Video DefaultMainSource: DefaultMa inSource
where
D efaultMainSource : 1/2/3/4
Set the source to be used as the main video source.
xConfiguration Video Input Connector [1..5] CameraControl Mode
Define whether the camera that is connected to this video input connector can be controlled or
not.
Note that camera control is not available for Connector 5 (S-video/Composite).
Requires user role: ADMIN
Default value: Connector 1, 2, 3: On Connector 4, 5: Off
USAGE:
xConfiguration Video Input Connector n CameraControl Mode: Mode
where
Mode : Connector 1, 2, 3, 4: Off/On Connector 5: Off
Off: Disable camera control.
On: Enable camera control.
xConfiguration Video Input Connector [1..5] CameraControl CameraId
The camera ID is a unique identifier of the cameras that are connected to the video input. Use
the xStatus Camera API command to see the IDs of the different cameras.
Requires user role: ADMIN
Default value: Connector n: n Connector 5: 1
USAGE:
xConfiguration Video Input Connector n CameraControl CameraId: CameraId
where
CameraId : Connector 1, 2, 3, 4: 1/2/3/4/5/6/7 Connector 5: 1
Select the ID of the camera.
xConfiguration Video Input Connector [1..5] InputSourceType
Select which type of input source is connected to the video input.
Requires user role: ADMIN
Default value: Connector 1 and 2: camera Connector 3 and 4: PC Connector 5: other
USAGE:
xConfiguration Video Input Connector n InputSourceType: InputSourceType
where
n : Index that identifies the input connector. Range: 1..5
InputSourceType : camera/PC/mediaplayer/document_camera/whiteboard/other
camera: Use this when a camera is connected to the video input.
PC: Use this when a computer is connected to the video input.
mediaplayer: Use this when a media player is connected to the video input.
document_camera: Use this when a document camera is connected to the video input.
whiteboard: Use this when a whiteboard camera is connected to the video input.
other: Use this when the other options do not match.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco TelePresence MX200 G2 Specifications

General

Resolution	1920 x 1080
Network	10/100/1000 Ethernet
Product Type	Video conferencing system
Display Size	42 in
Camera	PrecisionHD 1080p Camera
Codec	Cisco TelePresence Codec
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI
Control	Cisco Touch 10
Video Standards	H.264
Connectivity	HDMI
Codec Support	H.264
Resolution (fps)	1080p30
