Cisco TelePresence MX200 G2 Reference Guide

D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 127
Cisco TelePresence MX700 and MX800
API Reference Guide
xCommand Video Matrix Assign
xCommand Video Matrix commands are a smart overlay to the xCommand Video Layout
commands to make it easy to do simple video compositions.
Requires user role: USER
USAGE:
xCommand Video Matrix Assign [Mode: Mode] Output: Output SourceId: SourceId
where
Mode: Add/Replace
Choose whether to replace the existing source on that output rendered full screen or to
add it. Using Add, the layout engine will recompose the multiple sources automatically.
Replace is the default value.
Output: Integer (1..3)
Choose the output you wish to use for this layout.
SourceId: Integer (1..4)
The identifier (ID) of the input source. Input Source [n] has ID n. Run the following API
command to find the ID: xStatus Video Input Source.
xCommand Video Matrix Reset
Reset the content on the output to the default layout
xCommand Video Matrix commands are a smart overlay to the xCommand Video Layout
commands to make it easy to do simple video compositions.
Requires user role: USER
USAGE:
xCommand Video Matrix Reset [Output: Output]
where
Output: Integer (1..3)
Choose the output you want to reset.
xCommand Video Matrix Swap
Swap the content defined with xCommand Video Matrix Assign between two outputs.
xCommand Video Matrix commands are a smart overlay to the xCommand Video Layout
commands to make it easy to do simple video compositions.
Requires user role: USER
USAGE:
xCommand Video Matrix Swap OutputA: Outp utA OutputB: OutputB
where
OutputA: Integer (1..3)
The output you are swapping from.
OutputB: Integer (1..3)
The output you are swapping to.
xCommand Video Matrix Unassign
Remove a source from an output. Just as with xCommand Video Matrix Assign the layout
engine will recompose the remaining sources automatically.
xCommand Video Matrix commands are a smart overlay to the xCommand Video Layout
commands to make it easy to do simple video compositions.
Requires user role: USER
USAGE:
xCommand Video Matrix Unassign Output: Output SourceId: SourceId
where
Output: Integer (1..3)
Choose the output you wish to remove the source from.
SourceId: Integer (1..4)
The identifier (ID) of the input source. Input Source [n] has ID n. Run the following API
command to find the ID: xStatus Video Input Source.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xCommand

Cisco TelePresence MX200 G2 Specifications

General

Resolution	1920 x 1080
Network	10/100/1000 Ethernet
Product Type	Video conferencing system
Display Size	42 in
Camera	PrecisionHD 1080p Camera
Codec	Cisco TelePresence Codec
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI
Control	Cisco Touch 10
Video Standards	H.264
Connectivity	HDMI
Codec Support	H.264
Resolution (fps)	1080p30
