xConfiguration Cameras Camera [1..7] Backlight DefaultMode
This configuration turns backlight compensation on or off. Backlight compensation is useful
when there is much light behind the persons in the room. Without compensation the persons
will easily appear very dark to the far end.
Requires user role: USER
Default value: Off
USAGE:
xConfiguration Cameras Camera n Backlight Default Mode: DefaultMode
where
Default Mode : Off/On
Off: Turn off the camera backlight compensation.
On: Turn on the camera backlight compensation.
xConfiguration Cameras Camera [1..7] Brightness Mode
Define the camera brightness mode.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Brightness Mode: Mode
where
Mode : Auto/Manual
Auto: The camera brightness is automatically set by the system.
Manual: Enable manual control of the camera brightness. The brightness level is set
using the Cameras Camera [n] Brightness DefaultLevel setting.
xConfiguration Cameras Camera [1..7] Brightness DefaultLevel
Define the brightness level. Requires the Cameras Camera [n] Brightness Mode to be set to
Manual.
Requires user role: USER
Default value: 20
USAGE:
xConfiguration Cameras Camera n Brightness DefaultLevel: DefaultLevel
where
Defa ultLevel : Integer (1..31)
The brightness level.
xConfiguration Cameras Camera [n..7] Focus Mode
This setting applies to Camera [2..7] for single camera systems, and to HDMI [3..7] for dual
camera systems.
Define the camera focus mode.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Focus Mode: Mode
where
Mode : Auto/Manual
Auto: The camera will auto focus once a call is connected, as well as after moving the
camera (pan, tilt, zoom). The system will use auto focus only for a few seconds to set
the right focus; then auto focus is turned off to prevent continuous focus adjustments of
the camera.
Manual: Turn the autofocus off and adjust the camera focus manually.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco TelePresence MX200 G2 Specifications

General

Resolution	1920 x 1080
Network	10/100/1000 Ethernet
Product Type	Video conferencing system
Display Size	42 in
Camera	PrecisionHD 1080p Camera
Codec	Cisco TelePresence Codec
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI
Control	Cisco Touch 10
Video Standards	H.264
Connectivity	HDMI
Codec Support	H.264
Resolution (fps)	1080p30
