D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 126
Cisco TelePresence MX700 and MX800
API Reference Guide
Video commands
xCommand Video ActiveSpeakerPIP Set
Sets position for the active speakers PiP (picture in picture).
Requires user role: USER
USAGE:
xCommand Video ActiveSpeakerPIP Set Position: Position
where
Position: CenterLeft/CenterRight/LowerLeft/LowerRight/UpperCenter/UpperLeft/UpperRight
Select one of the predefined positions.
xCommand Video Input SetMainVideoSource
Set which input source is the main video source. You can identify the source either by the
identifier of the connector that it is connected to; or by the identifier of the source itself.
This command requires the use of one, and only one, of these parameters: ConnectorId or
SourceId.
Requires user role: USER
USAGE:
xCommand Video Input SetMainVideoSource [ConnectorId: ConnectorId] [Sou rceId:
SourceId]
where
ConnectorId: Integer (1..5)
The identifier (ID) of the connector. Connector [n] has ID n. Run the following API
command to find the ID: xStatus Video Input Connector. The connector ID is also printed
on the codec connector panel.
SourceId: Integer (1..4)
The identifier (ID) of the input source. Input Source [n] has ID n. Run the following API
command to find the ID: xStatus Video Input Source.
xCommand Video Input Source SetActiveConnector
Select which connector is active. Input Connector 4 (DVI-I) and Connector 5 (S-Video/
Composite) cannot be active simultaneously.
Requires user role: USER
USAGE:
xCommand Video Input Source SetActiveConnector [ConnectorId: ConnectorId]
where
ConnectorId: Integer (4..5)
The identifier (ID) of the connector. Connector [n] has ID n. Run the following API
command to find the ID: xStatus Video Input Connector. The connector ID is also printed
on the codec connector panel.
xCommand Video Layout LayoutFamily Set
Select the screen layout mode.
Requires user role: USER
USAGE:
xCommand Video Layout LayoutFa m ily Set [Target: Target] [: ] LayoutFa m ily:
LayoutFamily [C ustom L ayoutNa m e: "CustomLayoutName"]
where
Target: local/remote
Select if the target is the local layout or the remote layout.
: Integer (0..65534)
The CallID is returned when the xCommand Dial command is run. During the call you
can run the xStatus Call command to see the CallId.
LayoutFamily: auto/custom/equal/overlay/prominent/single
Select a layout family.
CustomLayoutName: String (1, 128)
Enter a name for the layout.
