D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 51
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Conference MultiStream Mode
The video system supports multistream video for conferences, provided that the conference
infrastructure supports the feature (Cisco TelePresence Server 4.2 or later). This means that
the video system can compose the video streams locally into a conference layout which utilizes
all available screens. This results in an enhanced user experience.
Multistream video is supported only via SIP.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Conference MultiStream Mode: Mode
where
Mode
: Auto/Off
Auto: Use local composition of video streams if the feature is supported by the confer-
ence infrastructure.
Off: Local composition is disabled. Layouts will be transcoded by the conference infra-
structure (Cisco TelePresence Server).
GPIO configuration
xConfiguration GPIO Pin [1..4] Mode
The four GPIO pins are configured individually. The state can be retrieved by "xStatus GPIO Pin
[1..4] State". The default pin state is High (+12 V). When activated as output, they are set to 0 V.
To activate them as input, they must be pulled down to 0 V.
Requires user role: ADMIN
Default value: InputNoAction
USAGE:
xConfiguration GPIO Pin n Mode: Mode
where
n
: GPIO pin number. Range: 1..4
Mode
: InputNoAction/OutputManualState/OutputInCall/OutputMicrophonesMuted/
OutputPresentationOn/OutputAllCallsEncrypted/OutputStandbyActive/
InputMuteMicrophones
InputNoAction: The pin state can be set, but no operation is performed.
OutputManualState: The pin state can be set by "xCommand GPIO ManualState Set
PinX: <High/Low>" (to +12 V or 0 V, respectively).
OutputInCall: The pin is activated when in call, deactivated when not in call.
OutputMicrophonesMuted: The pin is activated when microphones are muted, deacti-
vated when not muted.
OutputPresentationOn: The pin is activated when presentation is active, deactivated
when presentation is not active.
OutputAllCallsEncrypted: The pin is activated when all calls are encrypted, deactivated
when one or more calls are not encrypted.
OutputStandbyActive: The pin is activated when the system is in standby mode, deacti-
vated when no longer in standby.
InputMuteMicrophones: When the pin is activated (0 V), the microphones will be muted.
When deactivated (+12 V), the microphones are unmuted.
