Cisco TelePresence SX80 API Reference Guide
Using the command line
Help
To get a list of all supported top level commands you can
type ? or help after connecting to the TelePresence System
using RS-232, Telnet or SSH.
Bye
Typing the bye command closes the command line interface.
?
- User Commands -
help xcommand xconfiguration xevent xfeedback
xgetxml xdocument xpreferences xstatus bye
echo log systemtools
OK
API commands
xConfiguration
Configurations are system settings, such as system name
and network settings. These are persistent across boots.
Refer to ”Configurations” on page 16.
xCommand
Commands instruct the codec to execute actions, such as to
dial a number or to search the phone book.
Refer to ”Commands” on page 15.
xStatus
A status contains the current state of the codec, such as
connected calls, the status of the gatekeeper registration,
connected inputs and output sources.
Refer to ”Status” on page 17.
xFeedback
The Feedback commands are used to specify what parts of
the configuration and status hierarchies to monitor. Feedback
is only issued on the RS-232, Telnet or SSH session for which
it is specified. If you are connecting to the codec with multiple
sessions, you have to define feedback individually for each
session. Refer to ”Feedback mechanism” on page 19.
xPreferences
The xPreferences command is used to set preferences for
the RS-232, Telnet and SSH sessions.
Refer to ”API output” on page 12.
Echo <on/off>
If echo is set to On the key inputs are displayed when enter-
ing text in a command line interface.
If echo is set to Off no user input is displayed when entering
text in a command line interface.
xEvent
the xEvent command returns information on which events are
available for feedback. Refer to ”Events” on page 18.
xGetxml
The xGetxml request returns an XML document based on the
location parameter attached to the request. The elements
(or a complete document) matching the expression will be
returned. Refer to ”Feedback mechanism” on page 19.
Other commands
Systemtools
The systemtools commands are a set of command line tools
for administrative control and diagnostics. The commands
can be used for advanced troubleshooting together with
Cisco technical support. Systemtools are not a part of the
programming API. Refer to ”The SystemTools commands”
on page 228.
Log
The log command is used to enable advanced logs. It is only
used for debugging the system.
Command line shortcuts
If your client supports it, there are some timesaving shortcuts
you can use:
• Tab-completion to complete the commands and
arguments.
• Arrow up and arrow down keys to navigate your
command history.
• < C T R L- a > : Jump to the beginning of the line.
• < C T R L- e >: Jump to the end of the line.
• < C T R L- r > : Incremental command history search.
• < C T R L- w > : Erase the current line.
Contents
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus
About the API

Cisco TelePresence SX80 Specifications

General

Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.262, H.263, H.264, H.265
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.722, G.722.1, G.729ab
Noise reduction	Yes
HDMI ports quantity	5
DVI-D ports quantity	1
USB 2.0 ports quantity	2
Product color	Silver
Rack capacity	1U
Number of persons	0 person(s)
Analog signal format system	NTSC, PAL
Security algorithms	HTTPS, SSH
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	SIP, H.323, ISDN, TCP/IP, DHCP, QoS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sensor type	-
Image sensor size	- \

Weight and Dimensions

Depth	309.8 mm
Width	442 mm
Height	44 mm
Weight	3650 g
