Cisco TelePresence SX80 API Reference Guide
Addressing status information with xStatus
To read the status from the system type xStatus followed by a path (address expression):
xStatus <address expression>
Example 1: Query all ongoing Call information:
xStatus Call
*s Call 2 Status: Connected
*s Call 2 AnswerState: Answered
*s Call 2 CallPriority: None
*s Call 2 CallType: Video
*s Call 2 CallbackNumber: “sip:name@company.com”
*s Call 2 DeviceType: Endpoint
*s Call 2 Direction: Outgoing
*s Call 2 DisplayName: “Display Name”
*s Call 2 Duration: 15
*s Call 2 Encryption Type: “None”
*s Call 2 FacilityServiceId: 0
*s Call 2 ModifyState: Idle
*s Call 2 PlacedOnHold: False
*s Call 2 Protocol: “sip”
*s Call 2 ReceiveCallRate: 6000
*s Call 2 RemoteNumber: “name@company.com”
*s Call 2 TransmitCallRate: 4000
** end
Example 2: Query the protocol for a call:
xStatus Call Protocol
*s Call 2 Protocol: “sip”
OK
xstatus ?
- Status -
Audio GPIO Network Standby
Call H320 NetworkServices SystemUnit
Camera H323 Peripherals Time
Cameras HttpFeedback Preset UserInterface
Conference ICE Provisioning Video
Diagnostics Logging Security
Experimental MediaChannels SIP
OK
Status
A status contains the current state of the codec, such as
connected calls, the status of the gatekeeper registration,
connected inputs and output sources.
Writing xStatus ? on the command line lists all top level
statuses.
Writing xStatus lists all statuses and their current values.
To list out only some of the statuses, write xstatus followed by
the relevant part of the status path.
Contents
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus
About the API

Cisco TelePresence SX80 Specifications

General

Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.262, H.263, H.264, H.265
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.722, G.722.1, G.729ab
Noise reduction	Yes
HDMI ports quantity	5
DVI-D ports quantity	1
USB 2.0 ports quantity	2
Product color	Silver
Rack capacity	1U
Number of persons	0 person(s)
Analog signal format system	NTSC, PAL
Security algorithms	HTTPS, SSH
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	SIP, H.323, ISDN, TCP/IP, DHCP, QoS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sensor type	-
Image sensor size	- \

Weight and Dimensions

Depth	309.8 mm
Width	442 mm
Height	44 mm
Weight	3650 g
