Cisco TelePresence SX80 User Manual

D15107.0 5 Codec SX80 API Reference Guide TC7.3, OCTOBER 2015. Copyright © 2015 Cisco Systems, Inc. All rights reserved. 18
Cisco TelePresence SX80 API Reference Guide
Example 1: Outgoing Call Indication
Outgoing Call Indication is an event reported when an outgo-
ing call is about to be dialled. Returns the CallId the call has
been assigned.
*e OutgoingCallIndication CallId: x
** end
Example 2: Call Disconnect
Call Disconnect is an event reported when a call is discon-
nected. Returns the CallId of the disconnected call and
reason for the call’s disconnection.
*e CallDisconnect CallId: x CauseValue: 0
CauseString: “” CauseType: LocalDisconnect
OrigCallDirection: “outgoing”
** end
Example 3: Call Successful
Call Succesful is an event reported when a call is connected
successfully, that is when all channels are up and established.
*e CallSuccessful CallId: 132 Protocol: “h223”
Direction: “outgoing” CallRate: 768 RemoteURI:
“h223:integratorHQ@company.com” EncryptionIn:
“Off” EncryptionOut: “Off”
** end
Example 4: FECC Action request
FECC Action request is an event reported when far end is
sending FECC commands.
*e FeccActionInd Id: 132 Req: 1 Pan: 1 PanRight:
1 Tilt: 0 TiltUp: 0 Zoom: 0 ZoomIn: 0 Focus: 0
FocusIn: 0 Timeout: 300 VideoSrc: 0 m: 0
** end
Example 5: TString message received
TString message received is an event reported when far end
has sent a TString message.
*e TString CallId: 132 Message: “ee”
** end
Example 6: SString message received
SString message received is an event reported when far end
has sent a SString message.
*e SString String: “ee” Id: 132
** end
Events
Event returns information about the events that are available
for feedback. This overview presents examples of some the
events that are available on the API.
To get an overview of the supported events type ?, ?? or help
after xEvent:
• xEvent ? Lists the top level events
• xEvent ?? List all of the available events
• xEvent help Lists the top level events
The result for events depends on the state of the codec.
Contents
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus
About the API

Cisco TelePresence SX80 Specifications

General

Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.262, H.263, H.264, H.265
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.722, G.722.1, G.729ab
Noise reduction	Yes
HDMI ports quantity	5
DVI-D ports quantity	1
USB 2.0 ports quantity	2
Product color	Silver
Rack capacity	1U
Number of persons	0 person(s)
Analog signal format system	NTSC, PAL
Security algorithms	HTTPS, SSH
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	SIP, H.323, ISDN, TCP/IP, DHCP, QoS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sensor type	-
Image sensor size	- \

Weight and Dimensions

Depth	309.8 mm
Width	442 mm
Height	44 mm
Weight	3650 g
