Cisco TelePresence SX80 API Reference Guide

Using HTTP

The codec supports sending commands and configurations over HTTP and HTTPS. It is also possible to retrieve configurations

and statuses this way. This interface exposes the same API as the command line, but in XML format.

URL cheat sheet

The following table contains the main URLs used when accessing the API over HTTP.

Method URL Description

GET http://<ip-address>/status.xml Complete status document

GET http://<ip-address>/configuration.xml Complete configuration document

GET http://<ip-address>/command.xml Complete command document

GET http://<ip-address>/valuespace.xml Complete valuespace document

GET http://<ip-address>/getxml?location=<path> Retrieve document based on a path

POST http://<ip-address>/putxml Configurations and commands in HTTP body

GE T, POST http://<ip-address>/formputxml?xmldoc=<xml> Configurations and commands www-urlencoded

Getting status and configurations

Example 1: Get all status entries on the codec.

http://<ip-address>/getxml?location=/Status

Example 2: Get just the audio statuses of the codec.

http://<ip-address>/getxml?location=/Status/Audio

Example 3: Get all configurations of the codec.

http://<ip-address>/getxml?location=/Configuration

Example 4: Get all video configurations of the codec.

http://<ip-address>/getxml?location=/

Configuration/Video

Sending commands and configurations

Using HTTP GET

It is possible to use HTTP GET when sending commands

or configurations to the codec. This makes it easy to test

commands using your browser.

Example 1: Setting the camera position.

http://<ip-address>/formputxml?xmldoc=

Example 2: Changing the system name.

http://<ip-address>/formputxml?xmldoc=

<Name>newName</Name></SystemUnit></Configuration>

Example 3: Changing multiple configurations in one go.

http://<ip-address>/formputxml?xmldoc=

<Configuration><Audio><DefaultVolume>80</

DefaultVolume></Audio><UserInterface><Wallpaper>C

ustom</Wallpaper></UserInterface></Configuration>

Using HTTP POST

When sending configurations and commands to the codec,

it is important that the HTTP header Content-Type is set to

text/xml, i.e. Content-Type: text/xml. The body of the POST

should contain the XML content.

Example 1: Changing the system name.

Request

POST /putxml HTTP/1.1

Content-Type: text/xml

Connection: close

<Name>newName</Name>

</SystemUnit>

</Configuration>

Example 2: Setting the camera position.

Request

POST /putxml HTTP/1.1

Content-Type: text/xml

Connection: close

</PositionSet>

</Camera>

</Command>

Response

HTTP/1.1 200 OK

Date: <date>

Server: WSGIServer/0.1 Python/2.5.4

Cache-Control: no-cache

Content-Type: text/xml

Content-Length: 91

Connection: close

<?xml version=”1.0”?>

</Command>

Contents

Introduction

About the API

xConfiguration

Appendices

xCommand

xStatus

About the API

Cisco TelePresence SX80 Specifications

General

Maximum frame rate	60 fps
Supported video modes	720p, 1080p
Video formats supported	H.261, H.262, H.263, H.264, H.265
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecs	G.711, G.722, G.722.1, G.729ab
Noise reduction	Yes
HDMI ports quantity	5
DVI-D ports quantity	1
USB 2.0 ports quantity	2
Product color	Silver
Rack capacity	1U
Number of persons	0 person(s)
Analog signal format system	NTSC, PAL
Security algorithms	HTTPS, SSH
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	SIP, H.323, ISDN, TCP/IP, DHCP, QoS
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Sensor type	-
Image sensor size	- \
