control function accessed by an intercom panel. Labels
appear in the displays of the intercom panel.
Labels can identify panels, ports interfaced to other
external equipment, fixed groups, partylines, and
special control functions.
Multichannel Audio Digital Interface. The MADI or
AES10 electronic communications protocol defines the
data format and electrical characteristics of an
interface carrying multiple channels of digital audio.
The process by which two or more signals are
transmitted over a single communications channel.
Examples include time division and wavelength division
multiplexing.
Data stored in the CPU’s firmware (ROM) that is not
lost when the power is turned off.
The port, keyGroup and Monitor selection screen in
Production Maestro.
Any intelligent intercom device connected to the rear-
panel analog ports of the central matrix. This term
does not refer to devices connected through interface
modules.
A wired shared communication system based on a
single screened pair of wires. See the Encore range.
Matrix requires the CCI-22 to interface to it.
Any of the input/output connections (RJ-45
connectors) on the back panel of the central matrix.
These connectors and the attached cables connect the
central matrix to remote intercom devices. The term
port emphasizes that the connection is a portal
between the central matrix and the remote intercom
devices.
Any separate audio source that is fed into the intercom
channels. In television applications, for example, the
program audio is the audio that is broadcast on air.
Standardized unit of mounting space on a rack panel.
Each rack unit is 1.75 inches (44.45 mm) of vertical
mounting space. Therefore 1 RU is 1.75 inches (44.45
mm) of vertical mounting space, 2 RU is 3.5 inches
