InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
There is no function other than activation of the binary outputs Exerc Timer 1 or
Exerc Timer 2.
When this option is chosen, the Timer output is also internally connected to the
Remote OFF binary input.
When this option is chosen, the Timer directly starts gen-set (in AUT mode).
There is no other function besides binary output Exerc Timer 1 or Exerc Timer 2
activation.
When this option is chosen, the Timer output is also internally connected to the
Remote OFF binary input.
When this option is chosen, the Timer output is also internally connected to the
MainsFailBlock binary input.
When this option is chosen, the Timer output is also internally connected to the
Remote TEST binary input.
When this option is chosen, the Timer output is also internally connected to the Rem
TEST OnLd binary input.
The timer outputs are available as binary outputs Exerc Timer 1 and Exerc Timer 2.
NOTE:
Timers are activated even in the middle of the cycle. This means that even when the controller is
switched on after the moment when the timer should have been started and before it should have
finished, the timer is activated for the remainder of the duration period.
Timer functions can be activated only in AUT mode (not in OFF, MAN or TEST). There are 2 timers.
In the event that both Timers are active at the same time, Timer 1 has a higher priority than Timer 2.
6.17 Analog switches
One analog switch (comparator) is assigned to each analog input to the controller. The switches are
suitable for preheat control, day tank fuel pump control and others.
ï‚· Associated setpoints are located in the setpoint group Analog switches.
ï‚· One binary output is associated with each switch
The behaviour of the switch depends on the adjustment of the setpoints.
