ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
155
14.5 Binary inputs
Number of binary inputs
9
Galvanic insulation
Not insulated
Common pole
Positive, V
s
= 8–36 V DC
Closed contact voltage
<2 V
Open contact voltage
4 V - V
s
Input resistance
4.2 kΩ
14.6 Binary outputs
Number of binary outputs
8
Galvanic insulation
Not insulated
Type
Transistor, switching to negative supply terminal
Operating voltage
8–36 V DC
Switching current
500 mA (suppression diodes required for inductive loads)
Total current
2 A (overall current for all binary outputs)
14.7 Analog inputs
Number of analog inputs
3
Galvanic insulation
Not insulated
Electrical range
0–2500 Ω
Resolution
10 bits, 4 digits
Supported sensor types
Predefined: VDO 10Bar, VDO Temperature, VDO Fuel level
User-defined: 10 points non-linear sensors can be defined by the
user
Precision
1% from the range
14.8 Generator/Mains measurements
Measurement inputs
3ph generator voltage, 3ph generator current, 3ph mains voltage
Measurement type
True RMS
Voltage range
480 V Ph-Ph (277 V Ph-N)
Max. measured voltage
340 V Ph-N
Voltage accuracy
1% from the range
Current range
5 A
Max. measured current
9 A
Max. allowed current
12 A continuous, 50 A/1
Current accuracy
2% from the range
