InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
Binary output: Breaker Trip
The output is designed for auxiliary breaker tripping.
The output closes if:
- a fast opening of the GCB occurs due to any error (overcurrent, short
current etc.)
- any BOC or SD alarm appears or Emergency Stop is active
It opens if:
- No BOC and SD alarms are active and
- FAULT RESET is pressed
This output generates a 100 ms pulse whenever the internal kWh counter is
incremented.
16.4.2 ECU info
Binary output: ECU Comm OK
This output is active when an ECU is configured, connected and the
communication with the ECU is established.
Binary output: ECU Comm Error
This output is active when an ECU is configured, but the communication with
the ECU is not established or has dropped out.
Binary output: ECU YellowLamp
This output is active when the ECU sends an active “yellow lamp” flag, i.e. it
has detected a non-critical malfunction. This flag is taken from the DM1
frame on standard J1939 ECUs. Some ECUs provide this flag in their own
proprietary frames and some do not provide the flag at all.
