ComAp InteliCompact NT Reference Guide

InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
75
4.5.2 MINT
MINT only
BINARY INPUTS
NO.
DESCRIPTION
CONFIGURED FUNCTION
BI1
Generator circuit breaker feedback
GCB Feedback
BI2
Mains circuit breaker feedback
MCB Feedback
BI3
System start/stop
Sys Start/Stop
BI4
Emergency stop button
Emergency Stop
BI5
Access lock keyswitch
Access Lock
BI6
Highest priority switch
Top Priority
BI7
Large load preparation switch
Min Run Power
BI8
Warning alarm
None
BI9
Shutdown alarm
None
BINARY OUTPUTS
NO.
CONFIGURED FUNCTION
BO1
Starter
BO2
Fuel Solenoid
BO3
GCB Close/Open
BO4
BO5
Prestart
BO6
Alarm
BO7
Horn
BO8
SystReserve OK
ANALOG INPUTS
NO.
INPUT NAME
CONFIGURED SENSOR
AI1
Oil pressure
Sensor VDO 10 Bar, warning + shutdown alarm
AI2
Water temperature
Sensor VDO 120 deg, warning + shutdown alarm
AI3
Fuel level
Sensor VDO 180 Ohm, warning alarm
