InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
This output is dedicated to controlling the ignition at a gas engine. The
output is closed together with Fuel Solenoid in the moment the gen-set
reaches 30RPM during cranking. The output is opened when the gen-set
has stopped.
This output can be used for control of any device, which has to be activated
just before start, i.e. glow plugs. The output is closed for time period of
Prestart Time prior to activation of the starter motor and remains closed
during cranking and also during pause between cranking attempts.
Binary output: Cooling Pump
This output is dedicated for coolant pump control. It is closed in the moment
the gen-set is started and remains closed until the gen-set is stopped.
Binary output: Idle/Nominal
This output is used for switching between idle speed and nominal speed of
the engine during the startup phase, if this feature (input) is available on the
particular engine. In the case of some EFI engines, the idle/nominal
switching is performed over the communication bus.
The output is designed to be used as external alarm indication such as a red
bulb in the control room etc. The output is active when at least one
unconfirmed alarm is present in the alarmlist.
