16.1.10 Group: Volt/PF Ctrl
Setpoint: AVRi Bias
Group
Volt/PF Ctrl
Range [units]
0 ... 100.0 [%]
Related
applications
All
Description
This setpoint adjusts the initial PWM level for the AVR output, which is
present on the output, if no voltage or power factor regulation loop is active.
See the chapter AVR interface for details about the recommended settings
for various AVR types.
NOTE:
The voltage level on the AVR remote voltage input depends also on AVRi
output wiring and potentiometer position.
Setpoint: Voltage Gain
Group
Volt/PF Ctrl
Range [units]
0 … 200.0 [%]
Related
applications
All
Description
Gain of the voltage control PI loop.
Setpoint: Voltage Int
Group
Volt/PF Ctrl
Range [units]
0 ... 100 [%]
Related
applications
All
Description
Relative integration factor of the voltage control loop.
Setpoint: PF Gain
Group
Volt/PF Ctrl
Range [units]
0 ... 200.0 [%]
Related
applications
All
Description
Gain of power factor control PI loop.
