InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
Binary output: AL Common Stp
The output is closed when there is any slow stop type alarm present in the
alarmlist.
Binary output: AL Common BOC
The output is closed when there is any BOC type alarm present in the
alarmlist.
Binary output: AL Common Fls
The output is closed when there is any sensor fail alarm present in the
alarmlist.
Binary output: AL Exct Loss
This output gives the information about the status of the excitation loss
protection. It is active when the generator Excitation Loss alarm is present in
the alarm list.
16.4.4 MINT specific
Binary output: Bus Healthy
This output is active when the bus voltage and frequency are within limits. It
is deactivated with an appropriate delay after the voltage/frequency has got
out of limits. The limits for under/overvoltage and under/overfrequency as
well as appropriate delays are the same as for generator voltage/frequency
and can be found in the Gener protect setpoint group.
Binary output: System Ready
This output is closed if the gen-set group is able to take the current load and
keep the reserve greater than the currently selected reserve for start. This
output should be normally closed while the group works in automatic power
management mode. If the output is open, it means the whole gen-set group
is overloaded. It will open i.e. if a red alarm occurs on one gen-set and there
is no other gen-set available to start instead of the stopped one.
