InteliCompact
NT
, SW version 2.1
InteliCompact-NT-2.1-Reference Guide.pdf, ©ComAp – May 2015
The output designed to be used for acoustic indication of a newly appeared
alarm. The output is activated each time a new alarm has appeared and
remains active until one of the following events occurs:
ï‚· Fault reset is pressed
ï‚· Horn reset is pressed
ï‚· Horn Timeout has elapsed
Binary output: Fault Reset
The output is a copy of Fault Reset button on controller and binary input
FaultResButton.
Binary output: GCB Close/Open
This output is to be used for a contactor control in case a contactor is used
in the GCB position. See the chapter Circuit breakers for details about all
outputs available for generator/mains power switches.
Binary output: GCB ON Coil
This output is to be used for control of the ON coil of the generator circuit
breaker. See the chapter Circuit breakers for details about all outputs
available for generator/mains power switches.
Binary output: GCB OFF Coil
This output is to be used for control of the OFF coil of the generator circuit
breaker. See the chapter Circuit breakers for details about all outputs
available for generator/mains power switches.
Binary output: GCB UV Coil
This output is to be used for opening the generator circuit breaker via the
undervoltage coil. See the chapter Circuit breakers for details about all
outputs available for generator/mains power switches.
